Features

SHAFT
– SAE4150 steel shaft

BEARINGS
– Self-aligning spherical roller bearing (190mm)

ROTOR
– 3 bar solid rotor design (optional 4 bar segmented rotor)
– Stress relieved

IMPACT BARS
– Multiple chemistries available (950 lbs each)

CRUSHER HOUSING
– Fabricated 3/4” plate
– Stress relieved
– Rear section opens for easy access

PRIMARY APRON
– Fabricated 4” Hardox abrasive resistant steel
– Adjustable for gradation control
– Replaceable wear tips

SECONDARY APRON
– Fabricated 4” Hardox abrasive resistant steel
– Adjustable for gradation control
– Replaceable wear tips

ADJUSTMENT
– Screw type on primary hydraulic on secondary for easy
setting of crusher

CHAMBER LINERS
– 1-1/4” AR abrasive resistant steel
– 500 Bhn cast steel liners

LUBRICATION
– Grease system

CRUSHER DATA
HSI Feed Opening.......36” H x 60” W (914mm x 1523mm)
Rotor Dimensions...52” Dia x 60” W (1320mm x 1523mm)
Weight...................................................39,000 (17,691 kg)
RPM.......................................................................330-600
FPM....................................................................4000-8000
Recommended HP.................300-400 Electric, 600 Diesel
Approx. Capacities*.........................................300-450 tph
Maximum Feed Size
36” x 36” x 12” Recycle
18” - 21” 4 Bar
21” - 24” 3 Bar Limestone (10”-12” sec)
15” - 18” 4 Bar
18” - 21” 3 Bar Hard Rock (8”-10” sec)
Minimum Apron Setting              Primary 2”
                                                Secondary 1”

Specifications

Model

Rotor
(Diameter - Width) (in / mm)

Weight
(lbs / kg)

Capacity
(tph / mtph)

5260

52 - 60 / 1320 - 1523

39000 / 17591

450 / 408
