Features

Visibility

Optimal visibility over the drums
Efficient LED-lights for night-work
Sliding seat possibilities

Sprinkler system

Pressurized sprinkler system
Large water-tank
3 filtration system
Sprinkler timer

Performance

High vibration frequency
Dual frequency
High efficient eccentrics
Offset
Powerful Kubota engine

Transportation

Foldable ROPS
Flexible lifting/towing/tie down
possibilities in the forks
Central lifting point
Optimized machine length for
efficient transportation

Good ergonomics

Low noise
Easy to understand instrument panel
Comfortable vibration damped
operator platform
Driver lever following the sliding seat

Serviceability

Easy accessible daily servicepoints
Reliable sprinkler system
Cross-mounted engine for
best access
Dyn@Link (optional)

Specifications

Masses
Max. operating mass 20,700 lbs
Operating mass (incl. ROPS) 18,800 lbs
Operating mass (incl. Cab) 19,180 lbs
Module mass (front/rear) 9,400 lbs/ 9,400 lbs
Traction
Speed range 0-7.5 mph
Vertical oscillation ±7°
Theor. gradeability 39 %
Compaction
Split drums Yes
Centrifugal force (high/low amplitude) 16,190 lb/ 13,260 lb
Nominal amplitude (high/low) 0.020 in/ 0.008 in
Static linear load (front/rear) 152 / 152 lbs/in
Vibration frequency (high/low amplitude) 2,880 vpm/ 4,020 vpm
Water tank 198 gal
Engine
Manufacturer/Model Deutz TCD 3.6 HT T4f
Type Water cooled turbo diesel
Rated power, SAE J1995 74 hp @ 2,200 rpm
Fuel tank capacity 34 gal
Alternative Engine
Manufacturer/Model
Rated power, SAE J1995
Alternative Engine
Manufacturer/Model
Rated power, SAE J1995
Hydraulic system
Driving Axial piston pump with variable displacement
Axial piston motors (4) with variable displacement
Vibration Axial piston pumps (2) with variable displacement
Axial piston motors (2) with constant dispacement
Steering Gear pump with constant displacement.
Service brake Hydrostatic in forward and reverse lever.
Parking/Emergency brake Failsafe multidisc brake in both drums.
