Features

Visibility

Optimal visibility over the drums
Efficient LED-lights for night-work
Sliding seat possibilities

Sprinkler system

Pressurized sprinkler system
Large water-tank
3 filtration system
Sprinkler timer

Performance

High vibration frequency
Dual frequency
High efficient eccentrics
Offset
Powerful Kubota engine

Transportation

Foldable ROPS
Flexible lifting/towing/tie down
possibilities in the forks
Central lifting point
Optimized machine length for
efficient transportation

Good ergonomics

Low noise
Easy to understand instrument panel
Comfortable vibration damped
operator platform
Driver lever following the sliding seat

Serviceability

Easy accessible daily servicepoints
Reliable sprinkler system
Cross-mounted engine for
best access
Dyn@Link (optional)

Specifications

Masses
Max. operating mass 25,000 lbs
Operating mass (incl. ROPS) 22,500 lbs
Module mass (front/rear) 11,250 lbs/ 11,250 lbs
Traction
Speed range 0 - 7.5 mph
Vertical oscillation ±7°
Theor. gradeability 45 %
Compaction
Centrifugal force (high/low amplitude) 31,280 lb/ 20,700 lb
Nominal amplitude (high/low) 0.031 in/ 0.012 in
Static linear load (front/rear) 165 / 165 lbs/in
Vibration frequency (high/low amplitude) 3,060 vpm/ 4,020 vpm
Water tank 238
Engine
Manufacturer/Model Cummins QSB 4.5 IIIB/T4i
Type Water cooled turbo diesel
Rated power, SAE J1995 130 hp @ 2,200 rpm
Fuel tank capacity 63 gal
Alternative Engine
Manufacturer/Model
Type Water cooled turbo diesel
Rated power, SAE J1995
Alternative Engine
Manufacturer/Model
Hydraulic system
Driving Axial piston pump with variable displacement.
Axial piston motors (2) with variable displacement.
Vibration Axial piston pumps (2) with variable displacement.
Axial piston motors (2) with constant displacement.
Steering Gear pump with constant displacement.
Service brake Hydrostatic in forward and reverse lever.
Parking/Emergency brake Failsafe multidisc brake in both drums.
