Specifications

Masses
Operating mass (incl. ROPS) 16,500 lbs
Operating mass (incl. Cab) lbs
Module mass (front/rear) 8,800 lbs/ 7,700 lbs
Max. operating mass 19,400 lbs
Traction
Speed range 0-5
Tire size (8 ply) 14,9x24
Theor. gradeability 55 %
Vertical oscillation ±9°
Number of pads 132
Pad area 13.0 in2
Compaction
Nominal amplitude (high/low) 0.067 in/ 0.035 in
Vibration frequency (high/low amplitude) 1,860 vpm/ 2,580 vpm
Centrifugal force (high/low amplitude) 32,150 lb/ 30,580 lb
Engine
Manufacturer/Model Cummins QSB3.3
Type 4 cylindre Water cooled turbo diesel
Rated power, SAE J1995 80 hp @ 2,200 rpm
Fuel tank capacity 59 gal
Hydraulic system
Driving Axial piston pump with variable displacement
Axial piston motor with constant displacement.
Radial piston motor with constant displacement (D, PD).
Vibration Axial piston pump with variable displacement.
Axial piston motor (2) with variable displacement.
Steering Gear pump with constant displacement.
Service brake Hydrostatic in forward and reverse lever.
Parking/Emergency brake Failsafe multidisc brake in rear axle.
