Specifications

Masses
Operating mass (incl. ROPS) 26,700 lbs
Operating mass (incl. Cab) lbs
Module mass (front/rear) 15,450 lbs/ 11,250 lbs
Max. operating mass 29,550 lbs
Traction
Speed range 0-6
Tire size (8 ply) 23,1x26
Theor. gradeability 63 %
Vertical oscillation ±9°
Number of pads 130
Pad area 22 in2
Compaction
Static linear load lbs/in
Nominal amplitude, low 0.031 in
Nominal amplitude (high/low) 0.063 in/ 0.031 in
Vibration frequency (high/low amplitude) 1,980 vpm/ 1,980 vpm
Centrifugal force (high/low amplitude) 67,500 lb/ 32,850 lb
Engine
Manufacturer/Model Cummins QSB6.7 Tier3
Type Water cooled turbo diesel
Rated power 33.50 kW
Rated power 150.0 hp
Rated power @ 2,200 rpm
Rated power, SAE J1995 150.0 hp @ 2,200 rpm
Fuel tank capacity 85 gal
Hydraulic system
Driving Axial piston pump with variable displacement.
Axial piston motor with constant displacement.
Radial piston motors with constant displacement (D, PD).
Vibration Axial piston pump with variable displacement.
Axial piston motor (2) with variable displacement.
Steering Gear pump with constant displacement.
Service brake Hydrostatic in forward and reverse lever.
Parking/Emergency brake Failsafe multidisc brake in rear axle.
