Features

Tier 4 EPA Approved Engine

Magnum recognizes environmental responsibility and continues to meet emission regulations with the addition of their Interim & Tier 4 Generator line. The MLG15 generator is powered by a Mitsubishi diesel engine. Proven power you can trust, while maximizing fuel efficiency and high performance.
Affordable, Reliable, Mobile Power

The MLG15 diesel generator provides just the right combination of output, flexibility, ruggedness, efficiency and affordability for on-the-go, smaller-to-midsize, single phase power needs.
Features
Tough

Full tubular steel frame, with lockable enclosure
Durable, fade resistant, white baked on powder coat finish
Stainless steel hinges, exterior hardware and pad lockable door latches

Reliable

CSA Certified
Key switch to preheat (glow plug), start & stop
Automatic low oil level / high temp shutdown alerts
70A Start limit main breaker
2 year - 2,000 hour warranty
Marathon voltage regulation within +/- 1%

Ease for Your Users

Self-priming 4 cylinder Mitsubishi engine
External convenience outlets with individual breaker switches
External emergency stop switch

Warranty Responsibility: It is the responsibility and obligation of the purchaser to thoroughly read and understand the Magnum warranty prior to purchasing equipment. Failure to read and comprehend the warranty policy does not expose Magnum to any liabilities over and above the stated warranty bond. If you have any questions or need clarification of warranty details please call technical support at 800.437.2924.

Specifications

Output

3 Phase - Standby kW (kVA) N/A
Amps 480V (208V) N/A
3 Phase - Prime kW (kVA) N/A
Amps 480V (208V) N/A
1 Phase - Standby kW (kVA) 14.0 (14.0)
Amps 240V 58
1 Phase - Prime kW (kVA) 13.0 (13.0)
Amps 240V 54
AC Voltage 1-phase 120, 240
AC Voltage 3-phase N/A
Frequency Hz 60
Power Factor 1.0 (1 Phase)
Generator - Brand / Type / Insulation Marathon / Brushless / F
Sound (dB(A) 23 ft @ prime) 68

Size and Weight

Skid Mounted - L x W x H in (m) N/A
Dry Weight lbs (kg) N/A
Operating Weight lbs (kg) N/A
Trailer Mounted - L x W x H in (m) 105 x 68 x 56
  (2.67 x 1.73 x 1.42)
Dry Weight lbs (kg) 1425 (646)
Operating Weight lbs (kg) 1823 (827)

Engine

Type Interim Tier IV
Brand Mitsubishi
Aspiration Natural
Power - Prime @ 1800 rpm hp (kWm) 22.3 (16.6)
Displacement cubic in (L) 107 (1.8)
Cylinders 4
Speed rpm 1800
Fuel Consumption - Prime gph (Lph) 1.30 (4.92)

Capacities

Fuel Tank gal (L) 56 (212)
Approximate Run Time hrs 43
Coolant qt (L) 11.6 (11.0)

Electrical Distribution

Battery - 12V 1 - 12V 440 CCA Wet Cell
Main Circuit Breaker Size A 70
Voltage Selection N/A
Voltage Regulation +/-1%
120V - 20A GFI Duplex Outlets - qty 2
240V - 30A Twist Lock Outlets - qty 2
240V - 50A Twist Lock Outlets - qty 2

Trailer

Number of Axles 1
Capacity - Axle Rating lbs (kg) 2200 (998)
Tire Size in 15
Brakes N/A
Hitch 2" Ball
Maximum Tire Pressure psi 50

Options

Powertrain (Engine/Gen) • 60/40 Coolant
  • Heated Fuel Filter
  • Engine Heater - Lower Radiator Hose
  • Oil Drain Valve Kit
Controls • Battery, 720 CCA Gel Cell
  • Battery, 720 CCA Wet Cell
  • Battery, 685 CCA Gel Cell
  • No Battery
  • Battery Disconnect, Lockable
  • Battery Charger, 2 Amp
  • Alternative Outlet Panel Options (Consult factory for details)
Cabinet/Fuel Tank • Interior Cabinet Light
  • Level Indicator
  • 56 Gallon Fuel Tank
  • Fuel Tank Cap - Vent w/ Lanyard
  • Spare Tire & Carrier
  • Lift Structure
  • Liquid Containment/Quiet Pack
Trailer • Tube & Sleeve Jack
  • Combo Hitch - 2.5" Ring/2" Ball
  • 2.5" Ring
  • 3" Ring
  • 3" Ring (1.625 TH)
  • Plug Adapter, 4 Flat to 6 Round
  • Plug Adapter, 4 Flat to 7 Pin
  • Plug Adapter, 4 Flat to 7 Round Spade
  • Outrigger Package
