Features

Size: 3" x 3" (76 mm x 76 mm) NPT - Female.
Casing: Gray Iron 30.
Maximum Operating Pressure 87 psi (600 kPa).*
Semi-Open Type, Four Vane Impeller: Gray Iron 30.
Handles 3/4" (19,1 mm) Diameter Spherical Solids.
Impeller Shaft: Stainless Steel 316.
Replaceable Wear Plate: Carbon Steel 1026.
Pedestal: Gray Iron 30.
Seal Plate: Gray Iron 30.
Seal Sleeve: Stainless Steel 304.
Flap Valve: Gray Iron 30 and Buna-N w/Nylon Reinforcement.
Radial and Thrust Bearings: Open Single Row Ball.
Bearing Lubrication: SAE 30 Non-Detergent Oil.
Suction Flange: Gray Iron 25.
Gaskets: Vegetable Fiber.
Hardware: Standard Plated Steel.
Discharge Service Tee: Gray Iron 30.
Oil Level Sight Gage.
Optional Equipment: Strainer.
Consult Factory for Additional Options.
*Consult Factory for Applications Exceeding
Maximum Pressure and/or Temperature Indicated.

Specifications

Suction 3" (76 mm)
Discharge 3" (76 mm)
Solids Handling 0.75" (19 mm)
Solids Handling Cast Iron
Impeller Material Cast Iron
Seal Material Tungsten Carbide
Flange ASA
Drive Type Basic
