Features

Size: 3" x 2" (76 x 51 mm) Flanged.
Casing: (RS2A31-BAR) Ductile Iron 65-45-12.
(RS2A32-BAR) Cast Steel 70-36.
Maximum Operating Pressure 48 psi (331 kPa).*
Enclosed Type, Four Vane Impeller: Aluminum 356-T6.
Handles 1/4" (6,4 mm) Diameter Spherical Solids.
Impeller Shaft: Steel 1045.
Rotor: Copper Alloy C93200.
Bearing Housing: Ductile Iron 65-45-12.
Bearing Housing Lubrication: Grease.
Body Cover: (RS2A31-BAR) Ductile Iron 65-45-12.
(RS2A32-BAR) Cast Steel 70-36.
Center/Spacer Plate: (RS2A31-BAR) Ductile Iron 65-45-12.
(RS2A32-BAR) Cast Steel 70-36.
Suction Spool Flange: Cast Steel 70-36.
Radial Bearing: Permanently Sealed Single Row Ball Type.
Thrust Bearing: Permanently Sealed Single Row Ball Type.
Gaskets: Vegetable Fiber, PTFE and Cork.
Priming: Rotary Vane Type Priming Pump.
Air Release Valve : Cast Iron/Stainless Steel.
Optional Equipment: Cast Steel 70-36 Threaded Suction and Discharge
Companion Flange Kit, Copper Alloy C93700 Impeller, Group Grind with
Cast Iron Rotor (RS2A31-BAR Only),Stainless Steel 416 Impeller Shaft,
Buna-N Seal, PTFE Seal with Fluorocarbon O-Ring, PTFE Seal with Buna-
N O-Ring, Oil Filled Bearing Housing Assembly.
*Consult Factory for Applications Exceeding Maximum Pressure and/or Temperature Indicated.

Specifications

Suction 3" (76 mm)
Discharge 2" (51 mm)
Solids Handling 0.25" (6 mm)
Material Cast Steel
Impeller Material Aluminum
Seal Material Carbon/Ni-Resist
Flange ASA
Drive Type Basic
