Features

Size: 4” (102 mm) NPT Suction x 3” (76 mm) Flanged Discharge.
Casing: Gray Iron 30.
Maximum Operating Pressure 94 psi (648 kPa).*
Semi‐Open Type, Two Vane Impeller: Ductile Iron 65‐45‐12.
Handles 2‐1/2” (63,5 mm) Diameter Spherical Solids.
Impeller Shaft: Stainless Steel 17‐4PH.
Self‐Cleaning Replaceable Wear Plate: Carbon Steel 1015.
Shimless Adjustable Cover Plate: Gray Iron 30.
Externally Removable Flap Valve: Neoprene w/Nylon and Steel
Reinforcing.
Suction Flange/Flap Valve Seat: Gray Iron 30.
Bearing Housing: Gray Iron 30.
Seal: Cartridge Type, Mechanical, Oil‐Lubricated, Double Floating,
Self‐Aligning. Silicon Carbide Rotating and Stationary Faces.
Stainless Steel 304 Stationary Seat. Fluorocarbon Elastomers
(DuPont Viton or Equivalent). Stainless Steel 18‐8 Cage and
Spring. Maximum Temperature of Liquid Pumped, 160F (71C).* Seal Plate: Gray Iron 30.
Shaft Sleeve: Stainless Steel 17‐4PH.
Radial Bearing: Open Single Row Ball.
Thrust Bearing: Open Double Row Ball.
Bearing and Seal Cavity Lubrication: SAE 30 Non‐Detergent Oil.
Gaskets: Buna‐N, Compressed Synthetic Fibers, Vegetable Fiber,
PTFE, Cork, and Rubber.
O‐Rings: Buna‐N.
Hardware: Standard Plated Steel.
Brass Pressure Relief Valve.
Bearing and Seal Cavity Oil Level Sight Gauges.
* Consult Factory for Applications Exceeding Maximum .
Pressure and/or Temperature Indicated.

Specifications

Suction 4" (102 mm)
Discharge 3" (76 mm)
Solids Handling 2.5" (64 mm)
Material Cast Iron
Impeller Material Ductile Iron
Seal Material Silicon Carbide
Flange ASA
Drive Type Diesel Engine
