Features

Size: 6” (152 mm) NPT Suction x 4” (102 mm) Flanged Discharge.
Casing: Gray Iron 30. Maximum Operating Pressure 109 psi (752 kPa).* Semi‐Open Type, Two Vane Impeller: Ductile Iron 65‐45‐12.
Handles 3” (76,2 mm) Diameter Spherical Solids.
Impeller Shaft: Stainless Steel 17‐4PH.
Self‐Cleaning Replaceable Wear Plate: Carbon Steel ASTM A36.
Shimless Adjustable Cover Plate: Gray Iron 30.
Externally Removable Flap Valve: Neoprene w/Nylon and Steel
Reinforcing.
Suction Flange/Flap Valve Seat: Gray Iron 30.
Bearing Housing: Gray Iron 30.
Seal Plate: Gray Iron 30.
Seal: Cartridge Type, Mechanical, Oil‐Lubricated, Double Floating, Self‐
Aligning. Silicon Carbide Rotating and Stationary Faces. Fluorocarbon
Elastomers (DuPont Viton or Equivalent). Stainless Steel 316
Stationary Seat, Cage and Spring.
Maximum Temperature of Liquid Pumped, 160F (71C).* Shaft Sleeve: Stainless Steel 17‐4PH.
Radial and Thrust Bearings: Open Single Row Ball.
Bearing and Seal Cavity Lubrication: SAE 30 Non‐Detergent Oil.
Gaskets: Buna‐N, Compressed Synthetic Fibers, Vegetable Fiber, PTFE, Cork, and Rubber.
O‐Rings: Buna‐N.
Hardware: Standard Plated Steel.
Brass Pressure Relief Valve.
Bearing and Seal Cavity Oil Level Sight Gauges.
* Consult Factory for Applications Exceeding Maximum Pressure and/or Temperature Indicated.

Specifications

Suction 6" (152 mm)
Discharge 4" (102 mm)
Solids Handling 3" (76 mm)
Solids Handling Cast Iron
Impeller Material Ductile Iron
Seal Material Silicon Carbide
Flange ASA
Drive Type Diesel Engine
