Features

Size: 4” x 3” (102 mm x 76 mm).**
Casing: Gray Iron 30.
Maximum Operating Pressure 120 psi (827 kPa).*
Semi‐Open Type, Two Vane Impeller: Ductile Iron 65‐45‐12.
Handles 2‐1/2” (63,5 mm) Diameter Spherical Solids.
Impeller Shaft: Alloy Steel 4150.
Self‐Cleaning Replaceable Wear Plate: Carbon Steel 1015.
Shimless Adjustable Cover Plate: Gray Iron 30.
Externally Removable Flap Valve: Neoprene w/Nylon and Steel
Reinforcing.
Suction Flange/Flap Valve Seat: Gray Iron 30.
Bearing Housing: Gray Iron 30.
Seal Plate: Gray Iron 30.
Shaft Sleeve: Alloy Steel 4130.
Radial Bearing: Open Single Row Ball.
Thrust Bearing: Open Double Row Ball.
Bearing and Seal Cavity Lubrication: SAE 30 Non‐Detergent Oil.
Gaskets: Buna‐N, Compressed Synthetic Fibers, Vegetable Fiber, PTFE, Cork,
and Rubber.
O‐Rings: Buna‐N.
Hardware: Standard Plated Steel.
Brass Pressure Relief Valve.
Bearing and Seal Cavity Oil Level Sight Gauges.
Optional Equipment: Automatic Air Release Valve. High Pump Temperature
Shutdown Kit. Stainless Steel/G‐R Hard Iron Impeller, Seal Plate and Wear
Plate. Cartridge Seal w/Stainless Steel Sleeve. 120/240 Volt Casing Heater.
** Optional Gray Iron 30 Flanges Available as Follows (See Price Sheets):
3” Female NPT Discharge Flange Kit.
4” and 3” ASA Suction/Discharge Spool Flange Kits.
100 mm and 80 mm DIN 2527 (PN 16) Suction/Discharge Spool

Specifications

Suction 4" (102 mm)
Discharge 3" (76 mm)
Solids Handling 2.5" (64 mm)
Material Cast Iron
Impeller Material Ductile Iron
Seal Material Silicon Carbide
Flange ASA
Drive Type Basic
