Features

Size: 8” x 6” (203 mm x 154 mm).**
Casing: Gray Iron 30. Maximum Operating Pressure 129 psi (889 kPa).*
Semi‐Open Type, Two Vane Impeller: Ductile Iron 65‐45‐12. Handles 3” (76,2 mm) Diameter Spherical Solids.
Impeller Shaft: Alloy Steel 4150.
Self‐Cleaning Replaceable Wear Plate: Carbon Steel ASTM A36. Shimless Adjustable Cover Plate: Gray Iron 30.
Externally Removable Flap Valve: Neoprene w/Nylon and Steel Reinforcing.
Suction Flange/Flap Valve Seat: Gray Iron 30.
Bearing Housing: Gray Iron 30.
Seal Plate: Gray Iron 30.
Shaft Sleeve: Alloy Steel 4130.
Radial and Thrust Bearings: Open Double Row Ball.
Bearing and Seal Cavity Lubrication: SAE 30 Non‐Detergent Oil.
Gaskets: Buna‐N, Compressed Synthetic Fibers, Vegetable Fiber, PTFE, Cork and Rubber.
O‐Rings: Buna‐N.
Hardware: Standard Plated Steel.
Brass Pressure Relief Valve.
Bearing and Seal Cavity Oil Level Sight Gauges.
Optional Equipment: Automatic Air Release Valve. High Pump Temperature
Shutdown Kit. Stainless Steel/G‐R Hard Iron Impeller, Seal Plate and Wear Plate.
Cartridge Seal w/Stainless Steel Sleeve. 120/240 Volt Casing Heater.
** Optional Gray Iron 30 Flanges Available as Follows (See Price Sheets):
8” and 6” Female NPT Suction/Discharge Flange Kits.
8” and 6” ASA Suction/Discharge Spool Flange Kits.
200 mm and 150 mm DIN 2527 (PN 16) Suction/Discharge Spool Flange Kits.

Specifications

Suction 8" (203 mm)
Discharge 6" (152 mm)
Solids Handling 3" (76 mm)
Material Cast Iron
Impeller Material Ductile Iron
Seal Material Silicon Carbide
Flange ASA
Drive Type Basic
