Size: 4” x 3” (102 mm x 76 mm) - Flanged.**Casings: Gray Iron 30. Maximum Operating Pressure 176 psi (1213 kPa).*Semi‐Open Type, Two Vane Impellers: Ductile Iron 65‐45‐12.Handles 3” (76,2 mm) Diameter Spherical Solids.Impeller Shafts: Alloy Steel 4150.Self‐Cleaning Replaceable Wear Plates: Carbon Steel ASTM A36.Shimless Adjustable Cover Plates: Gray Iron 30.Suction Flange: Gray Iron 30.Bearing Housings: Gray Iron 30.Seal Plates: Gray Iron 30.Shaft Sleeves: Alloy Steel 4130.Radial Bearings: Open Single Row Ball.Thrust Bearings: Open Double Row Ball.Bearing and Seal Cavity Lubrication: SAE 30 Non‐Detergent Oil.Gaskets: Buna‐N, Compressed Synthetic Fibers, Vegetable Fiber, PTFE, Cork, and Rubber.O‐Rings: Buna‐N.Transition Chamber: Ductile Iron 65‐45‐12.Hardware: Standard Plated Steel.Brass Pressure Relief Valves.Bearing and Seal Cavity Oil Level Sight Gauges.Optional Equipment: Automatic Air Release Valve. High PumpTemperature Shutdown Kit. Stainless Steel/G‐R Hard IronImpellers, Wear Plates and Seal Plates. 120/240 Volt Casing Heater.** Optional Gray Iron 30 Flange Kits Available as Follows(See Price Sheets):3” Female NPT Discharge Flange Kit.4” and 3” ASA Suction/Discharge Spool Flange Kits.100 mm and 80 mm DIN 2527 (PN 16) Suction/Discharge Spool Flange Kits.
