Features

Size: 8” x 6” (203 mm x 154 mm) - Flanged.** Casings: Gray Iron 30.
Maximum Casing Pressure 257 psi (1772 kPa).*
Maximum Operating Pressure 250 psi (1723 kPa) at Temperatures up to 100F (37C) Based on System Component Limitations.*
Semi‐Open Type, Two Vane Impellers: Ductile Iron 65‐45‐12. Handles 3” (76,2 mm) Diameter Spherical Solids.
Impeller Shafts: Alloy Steel 4150.
Self‐Cleaning Replaceable Wear Plates: Carbon Steel ASTM A36.
Shimless Adjustable Cover Plates: Gray Iron 30.
Suction Flange: Gray Iron 30.
Bearing Housings: Gray Iron 30.
Seal Plates: Gray Iron 30.
Shaft Sleeves: Alloy Steel 4130.
Radial and Thrust Bearings: Open Double Row Ball.
Bearing and Seal Cavity Lubrication: SAE 30 Non‐Detergent Oil.
Gaskets: Buna‐N, Compressed Synthetic Fibers, Vegetable Fiber, PTFE, Cork, and Rubber.
O‐Rings: Buna‐N.
Transition Chamber: Ductile Iron 65‐45‐12.
Hardware: Standard Plated Steel.
Brass Pressure Relief Valves.
Bearing and Seal Cavity Oil Level Sight Gauges.
Optional Equipment: Automatic Air Release Valve. High Pump
Temperature Shutdown Kit. Stainless Steel/G‐R Hard Iron Impellers,
Wear Plates and Seal Plates. 120/240 Volt Casing Heater.
** Optional Gray Iron 30 Flange Kits Available as Follows
(See Price Sheets):
8” and 6” Female NPT Suction/Discharge Flange Kits.
8” and 6” ASA Suction/Discharge Spool Flange Kits.
200 mm and 150 mm DIN 2527 (PN 16) Suction/Discharge Spool Flange Kits

Specifications

Suction 8" (203 mm)
Discharge 6" (152 mm)
Solids Handling 3" (76 mm)
Material Cast Iron
Impeller Material Ductile Iron
Seal Material Silicon Carbide
Flange ASA
Drive Type Basic
