Features

New powerful crane
The crane is one of the forwarder's most essential components and is very important for productivity. We have kept this in mind with the new 165F, one of the market's most powerful cranes, with a high gross lifting and turning torque, and a weight-optimised linkage system that delivers high gross lifting force.

Protec as standard
It also has Protec, with shielded hose routing as standard, and new, split hose routing to the valve that improves ease of service.

Load capacity of a Giant
With a gross load of 20.000 kg and a load area of 5.2 m2 (6,9 with LoadFlex) this giant will boost your productivity.

High lift of dozer blade
The robust front blade can be lifted high for improved obstacle clearance.

New wheels
The new 20-ton wheels and 28.5- inch rims mean more traction force, higher ground clearance and low ground pressure.

Flexgate for safety and visibilty
Attachment of headbord to frame can flex in vertical direction which protects headbord and crane from accidental collisions. It can also "roll" if pushed in the corner. The design of the headboard also improve the visibility.

Komatsu Comfort Bogie
Powerful axle system and new bogie in robust construction of the portal type with the Comfort Bogie function produces the best combination of traction force and operator comfort.

Minimum downtime
The advantages of the new service-friendly frame system, ORFS couplings and lubricationfree universal joints provide high operational reliability and easy service.

Outstanding operator environment
Noticeably larger cab – higher and wider with more legroom, more storage space and a quiet working environment. Large glass surfaces mean better visibility upwards and to the sides, and make crane operation easier and more relaxed. The new operator's seat provides excellent comfort and work space, and offers many personal adjustments and settings. The new hand controls are ergonomically designed and well equipped.

Market leading control system
Full utilisation of MaxiXplorer provides you with everything from more exact and efficient machine control to marketleading operational and production follow-up.

Loadflex for greater efficiency
The Komatsu LoadFlex option, with optional hydraulic heightadjustable supports, ensures greater efficiency and ease of use when loading, unloading, and driving.

Specifications

Engine

DEF tank 18 l (4,76 gal) (for Stage IIIB/EPA Tier 4 engine)
Stroke volume 7,4 l
Torque 1,100 Nm (811 lb-ft) at 1,200 - 1,700 rpm
Power 193 kW DIN (259 HP) at 1,700 RPM.
Miscellaneous Water separator. Fuel filter. Throttle, electrical via CAN. Thermostat-controlled fan (electric). Electrical refuelling.
General info 74 AWI-4V, 6-cyl. diesel engine with turbo and intercooler. EPA Tier 4i and EU stage 3B. DEF/SCR post-treatment. (Stage II/EPA Tier 2 for Russia, Australia and South America)
Fuel tank 210 l (55 gal)
