Features

Flex Friction Control
Knife pressure and lifting force are controlled by sensors in the vertical knife to produce the least possible friction between trunk and head

Extra diameter measuring point
Optional extra measuring point for increased diameter measurement accuracy.

Plenty of options
Options and customisation capabilities encompass everything from measurement, feed rollers and the cutting unit to colour marking, stump processing and multi-tree equipment.

Chain tensioning
Option of equipping the head with either manual or automatic chain tensioning

Service friendliness
Easy service and maintenance with optimal access to all vital parts.

Reliable
Explanations behind the operational reliability range from the robust construction with a frame in high strength steel to smart hose routings and protected head components, such as the head computer.

Smart hose routing
Smart hose routing that minimises downtime

Specifications

Delimbing knives, number 4
Feed wheel type Steel rollers
Saw motor 19 cm3/rev (1.16 cu in/rev)
Bar 83,5 cm (32,9”),
Delimbing knives, opening, tip-to-tip 428 mm (16,9”)
Feed force, gross 26,6 (std), 29,0 (opt)
Feed speed 0-4,2 m/s (0-13,8 ft/s)
Fell/cut diam. theor. max 720 mm (28,3”)
Requisite max. hydraulic flow 280 l/min (61,6 gal/min)
Requisite max. hydraulic pressure 26 MPa (3771 psi)
Weight from 1345 kg (2965 lb)
