Komatsu AX50 Series Pneumatic

Double tap to zoom



Features

Great design starts on the smallest level and with the Komatsu AX50, no detail has been overlooked. Building on our 80-year history of superior engineering, the AX50 delivers improved performance and unbeatable strength for your most demanding applications. Using advanced Clean Air Technology, exhaust emissions are brought well below regulations to provide a more pleasant and productive work environment. The AX50 delivers the qualities you’ve come to count on in a Komatsu.

Specifications

General

GENERAL FG15HTU-20 FG18HTU-20
Power Type LPG LPG
Operation Type Sit-Down Sit-Down
Capacity @ 24 in. (600mm) Load Center 3,000 lbs 3,500 lbs
Load Distance  From Center Axle (2 Stage) 15.4 in 15.4 in
Wheelbase 55.1 in 55.1 in

Weight

WEIGHT  FG15HTU-20
 FG18HTU-20
Service Weight 6,230 lbs 6,700 lbs
Loaded Front 7,190 lbs 8,640 lbs
Loaded Rear 1,311 lbs 1,543 lbs
Unloaded Front 2,500 lbs 2,360 lbs
Unloaded Rear 3,730 lbs 4,340 lbs

Tires

TIRES FG15HTU-20 FG18HTU-20
Tire Type Pneumatic Pneumatic
Front 6.5 - 10 - 10PR (I) 6.5 - 10 - 10PR (I)
Rear 5 - 8 - 8PR (I) 5 - 8 - 8PR (I)
Number of Wheels, Front/Rear 2x / 2 2x / 2
Front 35 in 35 in
Rear 35.2 in 35.2 in

Dimensions

DIMENSIONS FG15HTU-20 FG18HTU-20
Tilting Angle, Forward/Backward 6 / 8 deg 6 / 8 deg
Lowered 85.5 in 85.5 in
Extended 176 in 176 in
Free Lift Height 5.5 in 5.5 in
Maximum Fork Height 128 in 128 in
Height Overhead Guard 81.5 in 81.5 in
Length, with Standard Forks 129.7 in 131.3 in
Length to Fork Face 87.6 in 89.2 in
Overall Width at Drive Tires 42.1 in 42.1 in
Forks, Thickness x Width x Length 1.6 x 4 x 42.1 in 1.6 x 4 x 42.1 in
Carriage Width/ITA Class 41 in / II 41 in / II
Ground Clearance, Under Mast 5.5 in 5.5 in
Ground Clearance, Center of Wheelbase 5.1 in 5.1 in
Right Angle Stacking Aisle 92.4 in 93.7 in
Turning Radius, Outside 77 in 78.3 in

Performance

PERFORMANCE FG15HTU-20 FG18HTU-20
Travel Speed, Loaded/Unloaded 11.8 / 12.4 mph 11.8 / 12.4 mph
Lifting Speed, Loaded/Unloaded 135 / 138 fpm 135 / 138 fpm
Lowering Speed, Loaded/Unloaded 98 / 98 fpm 98 / 98 fpm
Maximum Drawbar Pull, Loaded 3,700 lbs 3,700 lbs
Maximum Gradeability 39% 35%
Service Brake, Operation/Control Foot / Hydraulic Foot / Hydraulic
Parking Brake, Operation/Control Hand / Mechanical Hand / Mechanical
Steering Type FHPS FHPS

Drive

DRIVE FG15HTU-20 FG18HTU-20
Engine Manufacturer / Engine Model GCT / K21 GCT / K21
Rated Output (SAE Net) 56 HP @ 2,700 rpm 56 HP @ 2,700 rpm
Maximum Torque (SAE Net) 119 lb-ft @ 1,600 rpm 119 lb-ft @ 1,600 rpm
# of Cylinders / Displacement 4 / 126 cu in 4 / 126 cu in
Fuel Tank Capacity 11 US Gallons 11 US Gallons

Other

OTHER FG15HTU-20 FG18HTU-20
Relief Pressure, Maximum 2,650 psi 2,650 psi
Transmission Powershift Powershift
Sound Level  84 dB 84 dB
