Features

A better design that combines efficiency, reliability and serviceability.

  1. Excellent power-to-weight ratio
  2. Unique gas-charged piston maximizes hammer efficiency
  3. Simple, two-moving-parts design for reliability
  4. Separate ports for the NPK AutoLube system and an air line for underwater use
  5. Bottom tie rod nuts for easier serviceability (GH Models)
  6. Quick-change tool system with single round retainer pin
  7. Variety of tool configurations available
  8. Replaceable cylinder sleeves for easy, economical rebuild
  9. Tool bushings engineered for quick, easy replacement

Specifications

Operating Pressure 2,600 psi 180 bar
Impact Frequency 210 - 280 bpm 210 - 280 bpm
Impact Energy Class ft lbs** 20,000
Carrier Weight Range (tons) 120+ US tons 108+ Metric tons
Oil Flow 92 - 119 gpm 350 - 450 lpm
Working Weight 24,910 lb 11,300 kg
Tool Diameter 8.4 in 214 mm
Tool Working Length 39.7 in 1008 mm
