KPI-JCI Classifying Cyclones

Double tap to zoom



For a complete custom engineered fines recovery or specialty sand production plant, KPI-JCI offers dewatering screens, classifying cyclones, dewatering cyclones, pumps, attrition cells, density classifiers & sieve bend screens.  Building on KPI-JCI’s tradition of being a single source supplier, the addition of these products to the traditional washing & classifying product line gives KPI-JCI the ability to provide the equipment necessary to meet virtually any processing goals.


MODEL #CC 1.6/6 AND #CC 4/6
- Solid polyurethane cyclones
- Replaceable urethane vortex finger- Replaceable urethane apex/spigot
- Victaulic feed and overflow connections

MODEL #CC 6/6, #CC 6/10, #CC 10/10 & #CC 16/10
- Heavy duty fibre reinforced plastic (FRP) casing
- Concave, convex 360° spiral inlet head liner
- Snap fit, replaceable elastomer (i.e. - rubber) liners
- Stainless steel quick release clamp fasteners
- Replaceable urethane vortex finder
- Replaceable rubber apex/spigot

MODEL #CC 20/10, #CC 26/13, #CC 32/13
- Heavy duty fabricated steel or cast ductile iron casing
- Concave, convex 360° spiral inlet head liner
- Replaceable elastomer (i.e. - rubber) liners
- Bolt together cone sections
- Replaceable rubber lined vortex finder
- Replaceable rubber apex/spigot
