Link-Belt ATC-3275

• Excellent transportability - can be configured to meet some of the toughest transportation laws
• All manually offsettable fly options feature four offset positions of 2°, 15°, 30°, and 45°
• All hydraulically offsettable fly options feature offset positions from 2° to 45°
• New 12 ft (3.65 m) fly that is integral to on-board fly with 34.8 tons (31.57 mt) maximum capacity and two-line, one-load lift procedures
• "Stow 'n go" outrigger pontoons are easily secured for transport
• Next generation operator's cab with improved visibility and ergonomics
• Pull-out CabWalk for easy access to and from the operator's cab
• Integral air conditioning standard on upper and lower cabs
• Large removable engine hood doors for ease of service
• Job site travel with counterweight
• Tilting cab
• Outriggers with auto-leveling
• Access ladders and folding guardrails

275 USt (250 mt) ALL Terrain Crane

• 43.7 - 223 ft (13.3 - 68m) seven section formed full power latching boom
• Eight boom extend modes provide superior capacities
• Optional 12-40-67 ft (3.65 - 12.2 - 20.42m) three-piece, bi-fold, on-board lattice attachment with 2°, 15°, 30°, and 45° manual offsets, and 2° - 45° hydraulic offsets
• Optional two 25 ft (7.62m) plus 67 ft (20.42m) provide a total attachment length of 117 ft (35.66m)
• 350 ft (106.7m) maximum tip height
• Modular counterweights - 156,500 lbs (70 987kg)
• 22,510 lbs (100.13 kN) maximum winch line pull
• 420 fpm (128 m/min) maximum winch line speed
• Next generation tilting operator's cab
• Automated manual transmission with two-speed auxiliary transmission
• Anti-lock (ABS) disc brakes
• "Stow 'n Go" steel pontoons
