Size: 6” x 4” (152 mm x 102 mm) Flanged.Casing: Ductile Iron 65‐45‐12.Maximum Operating Pressure 159 psi (1096 kPa).*Enclosed Type, Two Vane Impeller: Ductile Iron 65‐45‐12. Handles 3” (76,2 mm) Diameter Spherical Solids.Suction Head: Gray Iron 30.Suction Spool: Gray Iron 30.Impeller Shaft: Alloy Steel 4150M.Replaceable Wear Ring: Ductile Iron 65‐45‐12.Pedestal: Gray Iron 30.Seal Plate: Gray Iron 30.Seal: Mechanical, Oil‐Lubricated. Silicon Carbide Rotating Face and Stationary Seat. Fluorocarbon Elastomers (DuPont Viton or Equivalent).Stainless Steel 316 Cage and Stainless Steel 18‐8 Spring. Maximum Temperature of Liquid Pumped 160F (71C).*Shaft Sleeve: Stainless Steel 303/304.Priming Chamber: Gray Iron 30 Housing w/Stainless Steel Float and Linkage.Discharge Check Valve: Ductile Iron Housing w/Buna‐N Flapper.Radial Bearing: Open Roller.Thrust Bearing: Open Double Ball.Bearing and Seal Cavity Lubrication: SAE 30 Non‐Detergent Oil. Gaskets: Vegetable Fiber.O‐Rings: Buna‐N.Hardware: Standard Plated Steel.Bearing and Seal Cavity Oil Level Sight Gauges.*Consult Factory for Applications Exceeding Maximum Pressure and/or Temperature Indicated.
