2022 Superior 60X32 Crusher - Jaw For Sale Stock E00062534

Interested in this machine? Send us a message

Fields with asterisks * are required

PriceWatch

Subscribe to be notified of price changes on this item.

2022 Superior Crusher - Jaw 60X32

Fields with asterisks * are required.
Print This Page
Description
RECYCLE CONVEYOR
Inventory ID
E00062534
Serial
2053595
Machine Status
  • Email a friend

    Send to a Friend

    Fields with asterisks * are required
  • Loan Calculator

    Loan Calculator

    Use the Loan Calculator to help you determine the financing and payment options that are best for you.

    Amount Financed ($)
    Interest Rate (%)
    Loan Term in Months
    Monthly Payment Calculated

    **The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.

Details

  • Inventory ID: E00062534
  • Status: On Rent
  • Make: Superior
  • Model: 60X32
  • Year: 2022
  • Serial#: 2053595

Notes

  • SUPERIOR PORTABLE 60X32 RECYCLE CONVEYOR EQUIPPED AS PER BELOW:
  • CONVEYOR FRAME:
    - CONSTRUCTION: DESIGNED TO ACCEPT FEED FROM SUPERIOR 3365 PORTABLE JAW PLANT
    AND DISCHARGE TO SIDE OF THE PLANT
    - MAIN FRAME: STRUCTURAL CHANNEL FRAMECONVEYOR FRAME
    - MAGNET: DINGS 55T CR INLINE SELF CLEANING SEVER DUTY MAGNET WITH DIRECT DRIVE
    - INCLUDES 8 KW RECTIFIER IN PANEL
    - INCLUDES SUPPORT STRUCTURE
    - PAN FEEDER: 48" X 72" PAN FEEDER WITH (2) 3 HP VIBRATING MOTORS
  • DRIVE SPECIFICATIONS:
    - DRIVE: CLASS I HEAD END
    - GEAR REDUCER: DODGE MTA RIGHT ANGLE SHAFT MOUNT
    - BACK STOP: INSTALLED IN REDUCER
    - MOTOR: 30 HP 1800 RPM TEFC
    - V-BELT DRIVE: NOT INCLUDED
    - CAPACITY: 850 STPH OF 100 PCF MATERIAL 25 DEGREE SURCHARGE LUMP SIZE 6"
    MINUS
    - BELT SPEED: 350 FPM
    - DRIVE PULLEY: 16" DIAMETER 3/8" HERRINGBONE LAGGED DRUM
    - TAIL PULLEY: 14" DIAMETER CEMA CHEVRON WING
    - SHAFTS: TURNED & POLISHED
    - BEARINGS: DODGE
    - TAKE UPS: SCREW TYPE
  • PORTABILITY:
    - CONVEYOR SPLICE: ONE PIECE CHANNEL FRAME
    - POWER UNIT: 9 HP HONDA POWER UNIT AND RESERVOIR
    - UNDERCARRIAGE: HYDRAULIC RAISE WITH PIN LOCKS INCLUDED
    - AXLE TYPE: FIXED WITH ROAD PORTABLE
    - TRANSPORT AXLE: DUAL (4) 11R-22.5 TIRES AND WHEELS
    - RADIAL AXLE: NOT INLCUDED
    - RADIAL TRAVLE: NOT INCLUDED
    - FIFTH WHEEL: FOR ROAD TRAVEL BOLT ON DESIGN
    - ANCHOR PIVOT: NOT INCLUDED
    - BRAKES: AIR BRAKES COMPLETE SYSTEM
    - LIGHTS: BRAKE AND DIRECTIONAL SIGNALS
    - AXLE JACKS: NOT INCLUDED
    - LANDING GEAR: HYDRAULIC RAISE AND LOWER
    - TOW-EYE: PINTLE TYPE HITCH
  • CONVEYOR COMPONENTS:
    - BELTING: MAXX ROCK SINGLE PLY STRAIGHT WARP 440 PIW 1/4 X 1/8 HAR BELT
    - BELT SPLICE: FACTORY VULCANIZED SPLICE
    - SCRAPER: SUPERIOR EXTERRA PRIMARY
    - SUPERIOR IDLERS: CEMA C 5" DIAMETER STEEL ROLLS SEALED FOR LIFE BALL BEARINGS
    - LOAD AREA: PICKING IDLERS 12-16" SPACING
    - TROUGH: PICKING IDLERS
    - RETURNS: STEEL ROLLS ON 10- SPACING
    - RADIAL HOPPER: NOT INCLUDED
    - GATHERING TROUGH: 5- LONG WITH ADJUSTABLE RUBBER FLASHING
    - GATHERING TROUGH: FULL LENGTH LOW-PROFILE STEEL SKIRTING
  • ADDITIONAL SPECIFICATIONS:
    - VOLTAGE: 480V/3PH/60HZ
    - CORD HOLDERS: (1) SET BENT PIPE STYLE
    - PAINT: 1 COAT PRIMER 1 COAT FINISH - PAINTED GRAPHITE GRAY (RAL 7024) WITH
    SAFETY YELLOW GUARDS
    - IDLER PAINT: POWDER COATED SUPERIOR ORANGE
    - OWNER-S MANUAL: (1) COPY IN ENGLISH INCLUDED FOR OPERATION AND MAINTENANCE
    - ELECTRICAL PANEL: CONTROL PANEL AND WIRING INCLUDED WITH 75- OF MAIN POWER
    CORD
  • - GUARDING: FOR DRIVE AND TAIL PULLEYS V-BELT DRIVE AND RETURN IDLERS. - GUARDS
    MAY NOT MEET ALL LOCAL CODES; CUSTOMER IS RESPONSIBLE TO HAVE GUARDING
    INSPECTED.
