2021 Superior Conveyor - Transfer 36X30CFC
Fields with asterisks * are required.
Print This Page
Description
SUPERIOR CONVEYOR
Inventory ID
E00060898
Serial
1875574
Machine Status
Equipment is on rent
Contact your Salesperson for more information
Contact your Salesperson for more information
Details
- Inventory ID: E00060898
- Status: On Rent
- Make: Superior
- Model: 36X30CFC
- Year: 2021
- Serial#: 1875574
Notes
- SUPERIOR 36X30CFC CHANNEL FRAME CONVEYOR EQUIPMENT AS PER BELOW:
- CONVEYOR FRAME:
- MAIN FRAME 8" X 11.5LB STRUCTURAL CHANNEL
- CROSS MEMBERS WELD IN - DRIVE SPECIFICATIONS:
- DRIVE CLASS I HEAD END
- GEAR REDUCER DODGE SHAFT MOUNT
- BACKSTOP NOT INCLUDED
- MOTOR 15 HP 1800 RPM TEFC
- V-BELT DRIVE WITH DRIVE GUARD
- CAPACITY 750 STPH OF 100PCF MATERIAL 25 DEGREE SURCHARGE (90% FINES 10%
SPHERICAL LUMPS 7" MINUS)
- BELT SPEED 400 FPM
-SUPERIOR PULLEYS CROWN FACE
-DRIVE PULLEY 14" DIAMETER 3/8" HERRINGBONE LAGGED DRUM
- TAIL PULLEY 12" DIAMETER CEMA CHEVRON›¼® WING
- SHAFTS TURNED AND POLISHED
- BEARINGS DODGE
- TAKE UPS SCREW TYPE - STATIONARY:
- CONVEYOR SPLICE ONE PIECEFRAME
- SUPPORTS SEE ADDED MODIFICATIONS - CONVEYOR COMPONENTS:
- BELTING 3-PLY-3/16X1/16 330PIW
- BELT SPLICE VULCANIZE SPLICE
- BELT SCRAPER SUPERIOR EXTERRA PRIMARY
- SUPERIOR IDLERS CEMA B 5" DIA. ROLLS SEALED FOR LIFE BALL BEARINGS
- IDLER BOLTS 4-BOLTS PER TROUGHING IDLER
- LOAD AREA 20 DEGREE TROUGH 16" SPACING
- TROUGH 35 DEGREE ON 4- SPACING
- RETURNS STEEL ROLLS ON 10- SPACING
- RECEIVING HOPPER NOT INCLUDED
- GATHERING TROUGH 5- LONG WITH ADJUSTABLE RUBBER FLASHING
- E-STOP NOT INCLUDED - ADDITIONAL SPECIFICATIONS:
- GUARDING FOR DRIVE AND TAIL PULLEYS V-BELT DRIVE AND RETURN IDLERS.
GUARDS MAY NOT MEET ALL LOCAL CODES; CUSTOMER IS RESPONSIBLE TO HAVE GUARDING
- ELECTRICAL: SWITCHGEAR WITH 150- OF MAIN POWER CORD
- PAINT SUPERIOR CLASS I GRAPHITE GRAY W/ YELLOW GUARDING
- GENERAL EQUIPMENT SIGN PLATE
- IDLER PAINT POWDER COATED SUPERIOR ORANGE
- OWNER-S MANUAL (1) COPY INCLUDED FOR OPERATION AND MAINTENANCE.
- ON-SITE SERVICE: NOT INCLUDED - ADDED MODIFICATIONS:
- EXTRA FRAME: UPPER FRAME PIECES
- TAIL STANDS: FRAME SUPPORT WITH PINS AND 5- UPRIGHT LEGS
- HEAD STAND: FRAME SUPPORT WITH PINS AND 7- UPRIGHT LEGS
- LIFTING EYES: (2)CROSS SUPPORTS WITH LIFTING EYES
